XS = Extra Space
Twin rudders and daggerboards, one on each float
This version is non-folding.
Available with diesel and hybrid motors.
Displacement above is lightships. Average displacement, subject to final options:9,350 kg / 20.613 lbs
Sail area:
-Main: 117 m² / 1,259 ft²
-Jib: 73 m² / 786 ft²
-Reacher: 150 m² / 1,614 ft²
-Staysail: 25 m² / 268 ft²
-Asym Spinnaker: 230 m² / 2,476 ft²
Evolution Non-BR
BYS
Max Prop
Discount Sails
Electric Yacht
SeaWaterPro
SBD App Non-BR
Hull: Trimaran Dbrd.
Beam overall (folded): 5.6 m / 18.33 ft
Sail area:
-Main: 108 m² / 1,162.5 ft²
-Solent: 57.5 m² / 618.9 ft²
-Staysail: 20.5 m² / 220.7 ft²
-Reacher: 166 m² / 1,786.8 ft²
-Asym. Spinnaker: 230 m² / 2,475.7 ft²
Sail Area:
-Main: 60.5 m² / 651.2 ft²
-Solent jib: 30.5 m² / 328.3 ft²
-Fore staysail: 21 m² / 226 ft²
-Storm jib: 7 m² / 75.3 ft²
-Gennaker: 101 m² / 1,087.2 ft²
-Code 0: 60.5 m² / 651.2 ft²
Sail area:
– Main: 53 m² / 570.49 ft²
– Optional main: 60 m² / 645.83 ft²
– Jib: 25.5 m² / 274.48 ft²
– Optional jib: 29.1 m² / 313.23 ft²
Tall rig measurements:
I – 14.3 m / 46.9 ft
J – 4.5 m / 14.76 ft
P – 16.5 m / 54.13 ft
E – 4.5 m / 14.76 ft
Sail area = 100% fore triangle.
Source: Multihill Dynamics – https://multihulldynamics.com
Available as either a trimaran or proa.
Center shell weight: 25 kg / 55.12 lbs.
Floats: 7kg / 15.43 lbs per float. Length: 2.8 m / 9.18 ft
Proa beam: 1.5 m / 4.9 ft
Sail area:
-Main: 5 m² / 53.8 ft²
-Genoa: 5 m² / 53.8 ft²
Folding trimaran.
Displacement = unladen weight
Beam folded: 3.0m / 9.83 ft
Available with carbon construction.
Carbon version:
– Unladen weight: 2,850 kg / 6,300 lbs
BOA (float to float CL): 7.98m (26.18 ft)
Displacement above is “lightship.”
Max displacement” 6,135kg / 13,525 lbs.
Reported sail area above is Main + Jib.
Sail area:
-Main: 65 m² / 699.7 ft²
-Jib: 68 m² / 731.95 ft²
-Self-tacking jib: 32 m² / 344.44 ft²
-Staysail: 13 m² / 139.9 ft²
-Asym: 152 m² / 1,636.1 ft²
Displacement above is “light.”
Max load displacement is 11,000 kg / 24,250 lbs.
Folding trimaran.
Beam folded: 2.5m / 8.17 ft
Available with carbon construction.
Sport version includes taller carbon mast, laminate sails and carbon bowsprit.
– SA = 62.9 sqm / 667 sqft
Displacement = unladen weight
