Classic 30' Catalina

8om0iNf8JnobrmdtuFlg1P7vDlgPvbinBIYS1873

Description

1980 30' Catalina sloop rigged, fin keel vessel is solid throughout, fully operational & easy to sail. Set up for long distance sails or dockside home. Lots of perks and pluses.

Price $14,900
Built 1980
Location Key West, FL
Name Cindy Thor
Email mscindythor@gmail.com
Phone (305)292-1217

Sailboat Specifications

Definitions
Hull Type: Fin w/spade rudder
Rigging Type: Masthead Sloop
LOA: 29.92 ft / 9.12 m
LWL: 25.00 ft / 7.62 m
S.A. (reported): 446.00 ft² / 41.43 m²
Beam: 10.83 ft / 3.30 m
Displacement: 10,200.00 lb / 4,627 kg
Ballast: 4,200.00 lb / 1,905 kg
Max Draft: 5.25 ft / 1.60 m
Construction: FG
Ballast Type: Lead
First Built: 1976
Last Built: 2008
# Built: 6430
Builder: Catalina Yachts (USA)
Designer: Frank Butler

Auxiliary Power/Tanks (orig. equip.)

Make: Var.
Type: Var.
Fuel: 21 gals / 79 L

Sailboat Calculations

Definitions
S.A. / Displ.: 15.22
Bal. / Displ.: 41.18
Disp: / Len: 291.43
Comfort Ratio: 24.93
Capsize Screening Formula: 2.00
S#: 1.64
Hull Speed: 6.70 kn
Pounds/Inch Immersion: 967.42 pounds/inch

Rig and Sail Particulars

HELP
I: 41.00 ft / 12.50 m
J: 11.50 ft / 3.51 m
P: 35.00 ft / 10.67 m
E: 11.50 ft / 3.51 m
S.A. Fore: 235.75 ft² / 21.90 m²
S.A. Main: 201.25 ft² / 18.70 m²
S.A. Total (100% Fore + Main Triangles): 437.00 ft² / 40.60 m²
S.A./Displ. (calc.): 14.92
Est. Forestay Length: 42.58 ft / 12.98 m
Mast Height from DWL: 45.92 ft / 14.00 m

Accommodations

Water: 43 gals / 163 L
Headroom: 6.25 ft / 1.91 m

Sailboat Links

Designers: Frank W. Butler
Builders: Catalina Yachts
Associations: Catalina 30/309 Association (IC30A)
Products: M&B SHIPCANVAS CO.
Sailboat Trailers
The Sail Warehouse
Related Sailboats: CATALINA 30
