Sailboat Specifications

Definitions
Hull Type: Keel/Cbrd.
Rigging Type: Masthead Sloop
LOA: 18.83 ft / 5.74 m
LWL: 16.16 ft / 4.93 m
S.A. (reported): 172.00 ft² / 15.98 m²
Beam: 6.25 ft / 1.91 m
Displacement: 1,100.00 lb / 499 kg
Max Draft: 3.25 ft / 0.99 m
Min Draft: 1.75 ft / 0.53 m
Construction: Wood or FG
First Built: 1959
Builder: Jouet (FRA)
Designer: Jean-Jacques Herbulot

KLSC Leaderboard

KLSC Leaderboard

Sailboat Calculations

Definitions
S.A. / Displ.: 25.87
Disp: / Len: 116.36
Comfort Ratio: 8.72
Capsize Screening Formula: 2.42
Hull Speed: 5.39 kn
Pounds/Inch Immersion: 360.88 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Jean-Jacques Herbulot
Builders: Jouët (FRA)
Yachting France (FRA)
Associations: CapCorse
