CONWAY 36 (WESTERLY)

CONWAY 36 (WESTERLY)
CONWAY 36 (WESTERLY)

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Masthead Sloop
LOA: 35.75 ft / 10.90 m
LWL: 30.25 ft / 9.22 m
Beam: 11.15 ft / 3.40 m
Displacement: 16,128.00 lb / 7,316 kg
Ballast: 7,168.00 lb / 3,251 kg
Max Draft: 6.00 ft / 1.83 m
Construction: FG
First Built: 1975
Last Built: 1982
Builder: Westerly Marine Ltd. (UK)
Designer: Laurent Giles

KLSC Leaderboard

KLSC Leaderboard

Auxiliary Power/Tanks (orig. equip.)

Make: Mercedes
Type: Diesel
Fuel: 42 gals / 159 L

Accomodations

Water: 75 gals / 284 L

Sailboat Calculations

Definitions
Bal. / Displ.: 44.44
Disp: / Len: 260.11
Comfort Ratio: 31.48
Capsize Screening Formula: 1.77
Hull Speed: 7.37 kn
Pounds/Inch Immersion: 1,205.17 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Jack Laurent Giles
Builders: Westerly Marine Construction Ltd.
Associations: Westerly Owners Association
Download Boat Record:

Notes

A twin keel version is called the SOLWAY 36.
Same hull as GALWAY, SOLWAY, and MEDWAY.
The CONWAY and SOLWAY 36's were center cockpits. The GALWAY (twin keel) and MEDWAY (deep fin keel) were aft cockpits.
Available as sloop or ketch.
Rebranded the Conway 36 MKII in 1979.
