Sailboat Specifications

Definitions
Hull Type: Keel/Cbrd.
Rigging Type: Cutter
LOA: 37.00 ft / 11.28 m
LWL: 30.00 ft / 9.14 m
S.A. (reported): 600.00 ft² / 55.74 m²
Beam: 10.17 ft / 3.10 m
Displacement: 11,500.00 lb / 5,216 kg
Ballast: 5,500.00 lb / 2,495 kg
Max Draft: 8.33 ft / 2.54 m
Min Draft: 3.75 ft / 1.14 m
Construction: FG
First Built: 1981
Builder: Dockrell (UK)(USA)

Auxiliary Power/Tanks (orig. equip.)

Make: Seapanther
Type: Diesel

Accomodations

Headroom: 6.17 ft / 1.88 m

Sailboat Calculations

Definitions
S.A. / Displ.: 18.91
Bal. / Displ.: 47.83
Disp: / Len: 190.15
Comfort Ratio: 25.21
Capsize Screening Formula: 1.81
S#: 2.63
Hull Speed: 7.34 kn
Pounds/Inch Immersion: 1,090.16 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 38.00 ft / 11.58 m
J: 15.00 ft / 4.57 m
P: 34.50 ft / 10.52 m
E: 12.00 ft / 3.66 m
S.A. Fore: 285.00 ft² / 26.48 m²
S.A. Main: 207.00 ft² / 19.23 m²
S.A. Total (100% Fore + Main Triangles): 492.00 ft² / 45.71 m²
S.A./Displ. (calc.): 15.50
Est. Forestay Length: 40.85 ft / 12.45 m
Mast Height from DWL: 44.00 ft / 13.41 m

Sailboat Links

Builders: Dockrell Yachts Ltd.
Associations: Dockrell Yachts Owners
Download Boat Record:

Notes

LOD: 35.5ft
SA includes staysail
