Sailboat Specifications

Definitions
Hull Type: Centerboard Dinghy
Rigging Type: Cat (unstayed)
LOA: 14.76 ft / 4.50 m
LWL: 13.29 ft / 4.05 m
S.A. (reported): 108.00 ft² / 10.03 m²
Beam: 4.95 ft / 1.51 m
Displacement: 320.00 lb / 145 kg
Max Draft: 2.79 ft / 0.85 m
Min Draft: 0.40 ft / 0.12 m
Construction: Wood or FG
First Built: 1949
# Built: 4300
Designer: Richard Sarby

Sailboat Calculations

Definitions
S.A. / Displ.: 36.98
Disp: / Len: 60.86
Comfort Ratio: 4.27
Capsize Screening Formula: 2.90
Hull Speed: 4.89 kn
Pounds/Inch Immersion: 235.06 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Notes

Olympic class since 1952.
