FIRST 36S7 (BENETEAU)

FIRST 36S7 (BENETEAU)
FIRST 36S7 (BENETEAU)

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 35.75 ft / 10.90 m
LWL: 31.08 ft / 9.47 m
S.A. (reported): 660.00 ft² / 61.32 m²
Beam: 12.42 ft / 3.79 m
Displacement: 11,684.00 lb / 5,300 kg
Ballast: 3,650.00 lb / 1,656 kg
Max Draft: 6.08 ft / 1.85 m
Construction: FG
First Built: 1996
Builder: Beneteau
Designer: Jean Berret

Auxiliary Power/Tanks (orig. equip.)

Type: Diesel
HP: 27
Fuel: 24 gals / 91 L

Accomodations

Water: 80 gals / 303 L

Sailboat Calculations

Definitions
S.A. / Displ.: 20.58
Bal. / Displ.: 31.24
Disp: / Len: 173.74
Comfort Ratio: 19.40
Capsize Screening Formula: 2.19
S#: 3.27
Hull Speed: 7.47 kn
Pounds/Inch Immersion: 1,379.27 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 44.62 ft / 13.60 m
J: 12.96 ft / 3.95 m
P: 41.67 ft / 12.70 m
E: 15.09 ft / 4.60 m
S.A. Fore: 289.14 ft² / 26.86 m²
S.A. Main: 314.40 ft² / 29.21 m²
S.A. Total (100% Fore + Main Triangles): 603.54 ft² / 56.07 m²
S.A./Displ. (calc.): 18.82
Est. Forestay Length: 46.46 ft / 14.16 m

Sailboat Links

Designers: Berret-Racoupeau
Philippe Stark
Builders: Beneteau
Download Boat Record:

Notes

Derived from the FIRST 35S7.
Deep keel: 6.92'
Wing keel: 4.83'.
Taller rig (IMS) also available. (P = 14.3m/46.92'.) Reported S.A. = 705 sqft
Not to be confused with the BENETEAU 36.7(FARR).
