FRIENDSHIP 22

FRIENDSHIP 22

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin w/transom hung rudder
Rigging Type: Fractional Sloop
LOA: 22.00 ft / 6.71 m
LWL: 18.50 ft / 5.64 m
S.A. (reported): 301.00 ft² / 27.96 m²
Beam: 8.20 ft / 2.50 m
Displacement: 3,500.00 lb / 1,588 kg
Max Draft: 4.26 ft / 1.30 m
Construction: FG
First Built: 1976
Builder: Jachtbouw Meijer (NL)
Designer: Jac. de Ridder

KLSC Leaderboard

KLSC Leaderboard

Sailboat Calculations

Definitions
S.A. / Displ.: 20.95
Disp: / Len: 246.78
Comfort Ratio: 16.77
Capsize Screening Formula: 2.16
S#: 2.56
Hull Speed: 5.76 kn
Pounds/Inch Immersion: 542.04 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 23.20 ft / 7.07 m
J: 18.10 ft / 5.52 m
P: 23.10 ft / 7.04 m
E: 7.90 ft / 2.41 m
S.A. Fore: 209.96 ft² / 19.51 m²
S.A. Main: 91.25 ft² / 8.48 m²
S.A. Total (100% Fore + Main Triangles): 301.21 ft² / 27.98 m²
S.A./Displ. (calc.): 20.96
Est. Forestay Length: 29.43 ft / 8.97 m

Sailboat Links

Designers: Jacques De Ridder
Builders: Friendship Yachts (NL)
Associations: International Friendship Club
Download Boat Record:
