Sailboat Specifications

Definitions
Hull Type: Fin w/bulb & spade rudder
Rigging Type: Fractional Sloop
LOA: 62.34 ft / 19.00 m
LWL: 56.10 ft / 17.10 m
S.A. (reported): 2,111.00 ft² / 196.12 m²
Beam: 17.06 ft / 5.20 m
Displacement: 52,249.00 lb / 23,700 kg
Ballast: 19,621.00 lb / 8,900 kg
Max Draft: 9.68 ft / 2.95 m
Construction: FG
Ballast Type: Lead
First Built: 2006
Builder: Hanse Yachts
Designer: Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Make: Yanmar
Type: Diesel
HP: 110
Fuel: 158 gals / 598 L

Accomodations

Water: 211 gals / 799 L

Sailboat Calculations

Definitions
S.A. / Displ.: 24.28
Bal. / Displ.: 37.55
Disp: / Len: 132.11
Comfort Ratio: 31.87
Capsize Screening Formula: 1.83
S#: 4.68
Hull Speed: 10.04 kn
Pounds/Inch Immersion: 3,419.70 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 84.45 ft / 25.74 m
J: 22.83 ft / 6.96 m
P: 83.76 ft / 25.53 m
E: 27.43 ft / 8.36 m
S.A. Fore: 964.00 ft² / 89.56 m²
S.A. Main: 1,148.77 ft² / 106.72 m²
S.A. Total (100% Fore + Main Triangles): 2,112.77 ft² / 196.28 m²
S.A./Displ. (calc.): 24.30
Est. Forestay Length: 87.48 ft / 26.66 m

Sailboat Links

Designers: Judel/Vrolijk & Co.
Builders: Hanse Yachts
Download Boat Record:

Notes

Standard layout shown here. A number of different layouts available.
