Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Masthead Sloop
LOA: 33.14 ft / 10.10 m
LWL: 24.61 ft / 7.50 m
S.A. (reported): 620.00 ft² / 57.60 m²
Beam: 10.33 ft / 3.15 m
Displacement: 9,722.00 lb / 4,410 kg
Ballast: 3,748.00 lb / 1,700 kg
Max Draft: 6.07 ft / 1.85 m
Construction: FG
First Built: 1976
Last Built: 1980
Builder: Yachting France (FRA)
Designer: Yves Mareschal

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo
Type: Diesel
Fuel: 18 gals / 68 L

Accomodations

Water: 53 gals / 201 L

Sailboat Calculations

Definitions
S.A. / Displ.: 21.85
Bal. / Displ.: 38.55
Disp: / Len: 291.19
Comfort Ratio: 24.66
Capsize Screening Formula: 1.94
Hull Speed: 6.65 kn
Pounds/Inch Immersion: 908.36 pounds/inch
