KING'S CRUISER 33

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Masthead Sloop
LOA: 33.67 ft / 10.26 m
LWL: 24.00 ft / 7.32 m
S.A. (reported): 441.00 ft² / 40.97 m²
Beam: 10.25 ft / 3.12 m
Displacement: 9,480.00 lb / 4,300 kg
Ballast: 4,410.00 lb / 2,000 kg
Max Draft: 5.67 ft / 1.73 m
Construction: FG
Ballast Type: Iron
First Built: 1972
Last Built: 1978
# Built: 150
Builder: OY Fiskars AB (FIN)
Designer: Pelle Pettersson

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo
Type: Diesel
Fuel: 100 gals / 379 L

Accomodations

Water: 100 gals / 379 L

Sailboat Calculations

Definitions
S.A. / Displ.: 15.81
Bal. / Displ.: 46.52
Disp: / Len: 306.14
Comfort Ratio: 24.54
Capsize Screening Formula: 1.94
S#: 1.61
Hull Speed: 6.56 kn
Pounds/Inch Immersion: 878.99 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
I: 41.40 ft / 12.62 m
J: 11.50 ft / 3.51 m
P: 36.90 ft / 11.25 m
E: 11.00 ft / 3.35 m
S.A. Fore: 238.05 ft² / 22.12 m²
S.A. Main: 202.95 ft² / 18.85 m²
S.A. Total (100% Fore + Main Triangles): 441.00 ft² / 40.97 m²
S.A./Displ. (calc.): 15.81
Est. Forestay Length: 42.97 ft / 13.10 m
