Sailboat Specifications

Definitions
Hull Type: Centerboard Dinghy
Rigging Type: Fractional Sloop
LOA: 13.25 ft / 4.04 m
LWL: 12.75 ft / 3.89 m
S.A. (reported): 120.00 ft² / 11.15 m²
Beam: 5.50 ft / 1.68 m
Displacement: 185.00 lb / 84 kg
Max Draft: 3.75 ft / 1.14 m
Min Draft: 0.33 ft / 0.10 m
Construction: FG
First Built: 1967
# Built: 12000
Builder: Parker Boats/John Baker Ltd.
Designer: Michael Jackson

Sailboat Calculations

Definitions
S.A. / Displ.: 59.18
Disp: / Len: 39.85
Comfort Ratio: 2.29
Capsize Screening Formula: 3.86
Hull Speed: 4.78 kn
Pounds/Inch Immersion: 250.56 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Notes

Spin: 80 sqft.
