Sailboat Specifications

Definitions
Hull Type: Fin Keel
Rigging Type: Masthead Sloop
LOA: 29.86 ft / 9.10 m
LWL: 23.29 ft / 7.10 m
Beam: 9.68 ft / 2.95 m
Displacement: 9,259.00 lb / 4,200 kg
Ballast: 4,189.00 lb / 1,900 kg
Max Draft: 4.59 ft / 1.40 m
Construction: FG
First Built: 1988
Builder: Mascot Boats (DEN)
Designer: Palle Mortensen

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo Penta
Type: Diesel
HP: 37
Fuel: 42 gals / 159 L

Accomodations

Water: 42 gals / 159 L

Sailboat Calculations

Definitions
Bal. / Displ.: 45.24
Disp: / Len: 327.20
Comfort Ratio: 27.54
Capsize Screening Formula: 1.85
Hull Speed: 6.47 kn
Pounds/Inch Immersion: 805.55 pounds/inch
