Beta Marine

Sailboat Specifications

Definitions
Hull Type: Keel/Cbrd.
Rigging Type: Fractional Sloop
LOA: 18.37 ft / 5.60 m
LWL: 15.81 ft / 4.82 m
S.A. (reported): 156.00 ft² / 14.49 m²
Beam: 7.15 ft / 2.18 m
Displacement: 1,653.00 lb / 750 kg
Ballast: 441.00 lb / 200 kg
Max Draft: 4.00 ft / 1.22 m
Min Draft: 1.15 ft / 0.35 m
Construction: FG
First Built: 1964
Builder: La Prairie (FRA)
Designer: J. J. Hurbulot

KLSC Leaderboard

Sailboat Calculations

Definitions
S.A. / Displ.: 17.89
Bal. / Displ.: 26.68
Disp: / Len: 186.74
Comfort Ratio: 11.21
Capsize Screening Formula: 2.42
Hull Speed: 5.33 kn
Pounds/Inch Immersion: 403.91 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Jean-Jacques Herbulot
Builders: La Prairie (FRANCE)
Download Boat Record:
