Sailboat Specifications

Definitions
Hull Type: Centerboard Dinghy
Rigging Type: Fractional Sloop
LOA: 14.00 ft / 4.27 m
LWL: 14.00 ft / 4.27 m
S.A. (reported): 145.00 ft² / 13.47 m²
Beam: 5.00 ft / 1.52 m
Displacement: 360.00 lb / 163 kg
Max Draft: 5.00 ft / 1.52 m
Min Draft: 0.75 ft / 0.23 m
Construction: Wood
First Built: 1939
# Built: 250
Designer: Uffa Fox

Sailboat Calculations

Definitions
S.A. / Displ.: 45.90
Disp: / Len: 58.57
Comfort Ratio: 4.65
Capsize Screening Formula: 2.81
Hull Speed: 5.01 kn
Pounds/Inch Immersion: 250.12 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: Uffa Fox
Builders: GoodWood Boat Co. (UK)
Associations: National Redwing Class Site
Download Boat Record:

Notes

Thanks to Bill Dowell, Class Secretary of the Redwing Dinghy Class, for providing updated information on this boat.
