Sailboat Specifications

Definitions
Hull Type: Fin with rudder on skeg
Rigging Type: Masthead Sloop
LOA: 65.68 ft / 20.02 m
LWL: 55.08 ft / 16.79 m
S.A. (reported): 2,088.00 ft² / 193.98 m²
Beam: 17.50 ft / 5.33 m
Displacement: 75,500.00 lb / 34,246 kg
Ballast: 31,700.00 lb / 14,379 kg
Max Draft: 11.50 ft / 3.51 m
Construction: FG
Ballast Type: Lead
First Built: 1982
Last Built: 1991
# Built: 19
Builder: Nautor
Designer: German Frers

Auxiliary Power/Tanks (orig. equip.)

Make: Perkins
Type: Diesel
HP: 120

Sailboat Calculations

Definitions
S.A. / Displ.: 18.79
Bal. / Displ.: 41.99
Disp: / Len: 201.71
Comfort Ratio: 44.30
Capsize Screening Formula: 1.66
Hull Speed: 9.94 kn
Pounds/Inch Immersion: 3,444.12 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: German Frers
Builders: Nautor (Swan sailboats)
Download Boat Record:

Notes

Keel/CB version available.
