VICTOIRE V35

VICTOIRE V35

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Fin w/spade rudder
Rigging Type: Masthead Sloop
LOA: 35.56 ft / 10.84 m
LWL: 27.56 ft / 8.40 m
S.A. (reported): 581.00 ft² / 53.98 m²
Beam: 10.63 ft / 3.24 m
Displacement: 12,302.00 lb / 5,580 kg
Ballast: 6,063.00 lb / 2,750 kg
Max Draft: 6.23 ft / 1.90 m
Construction: FG
First Built: 2005
Builder: Victoire Yachts (NED)
Designer: Dick Koopmans Sr.

Auxiliary Power/Tanks (orig. equip.)

Make: Volvo Penta
Model: D1-30
Type: Diesel
Fuel: 21 gals / 79 L

Accomodations

Water: 53 gals / 201 L

Sailboat Calculations

Definitions
S.A. / Displ.: 17.51
Bal. / Displ.: 49.28
Disp: / Len: 262.36
Comfort Ratio: 27.24
Capsize Screening Formula: 1.85
Hull Speed: 7.03 kn
Pounds/Inch Immersion: 1,046.79 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Rig and Sail Particulars

HELP
Mast Height from DWL: 49.21 ft / 15.00 m

Sailboat Links

Designers: Dick Koopmans
Builders: Victoire Yachts (NL)
Associations: Victoire Club (NL)
Download Boat Record:

Notes

Shoal draft: 4.92'/1.5m
Updated version of the VICTOIRE 1044.
