MORGAN 41 OUT ISLAND KETCH

Uz9E9lxgLdAWdpPJlmvFundxiVJUAW81Tql0RHrQ

Description

The sailboat is in operational conditions , engine revised and going smoothly , sails in great coditions , two anchors , interior has nice kitchenet with running water ,2 revised bathrooms , marine fuel stove , great inner refrigrerator , two radios , depth founder , 2 separate cabins plus the central . needs some decorations touches ,inflatable dinghy , OVERALL is SEAWORTHY and sailing .

Price $28,000
Built 1974
Location PORT HUDSON MARINA , HUDSON ,FLORIDA
Name DAVID LAWSON AND JOSE MANUEL FIGUEROA
Email jmfigueroaml@hotmail.com
Phone (813) 781-7900 (USA), and +34610775319 (Spain)

Sailboat Specifications

Definitions
Hull Type: Long Keel
Rigging Type: Masthead Ketch
LOA: 41.25 ft / 12.57 m
LWL: 34.00 ft / 10.36 m
S.A. (reported): 792.00 ft² / 73.58 m²
Beam: 13.82 ft / 4.21 m
Displacement: 27,000.00 lb / 12,247 kg
Ballast: 9,000.00 lb / 4,082 kg
Max Draft: 4.17 ft / 1.27 m
Construction: FG
Ballast Type: Lead
First Built: 1972
Builder: Morgan Yachts (USA)
Designer: Charles Morgan

Auxiliary Power/Tanks (orig. equip.)

Make: Perkins
Type: Diesel
HP: 62
Fuel: 138 gals / 522 L

Sailboat Calculations

Definitions
S.A. / Displ.: 14.14
Bal. / Displ.: 33.33
Disp: / Len: 306.68
Comfort Ratio: 34.93
Capsize Screening Formula: 1.85
S#: 1.27
Hull Speed: 7.81 kn
Pounds/Inch Immersion: 1,678.93 pounds/inch

Rig and Sail Particulars

HELP
I: 49.00 ft / 14.94 m
J: 17.00 ft / 5.18 m
P: 42.25 ft / 12.88 m
E: 12.00 ft / 3.66 m
PY: 27.00 ft / 8.23 m
EY: 9.00 ft / 2.74 m
S.A. Fore: 416.50 ft² / 38.69 m²
S.A. Main: 253.50 ft² / 23.55 m²
S.A. Total (100% Fore + Main Triangles): 670.00 ft² / 62.25 m²
S.A./Displ. (calc.): 11.96
Est. Forestay Length: 51.87 ft / 15.81 m
Mast Height from DWL: 53.00 ft / 16.15 m

Accomodations

Water: 170 gals / 644 L
