Sailboat Specifications
Hull Type:
Swing Keel
Rigging Type:
Fractional Sloop
LOA:
16.90 ft / 5.15 m
LWL:
15.58 ft / 4.75 m
Beam:
6.10 ft / 1.86 m
S.A. (reported):
125.00 ft2 / 11.61 m2
Draft (max):
3.54 ft / 1.08 m
Draft (min):
0.62 ft / 0.19 m
Displacement:
783 lb / 355 kg
Ballast:
176 lb / 80 kg
S.A./Disp.:
23.58
Bal./Disp.:
22.48
Disp./Len.:
92.43
Construction:
FG
First Built:
1970
Last Built:
1975
# Built:
450
Builder:
Lanaverre (FRA)
Designer:
Christian Maury
Website:
www.facebook.com/Lanaverre510
Sailboat Calculations
S.A./Disp.:
23.58
Bal./Disp.:
22.48
Disp./Len.:
92.43
Comfort Ratio:
6.81
Capsize Screening Formula:
2.65
Sailboat Links
Designers:
Builders:
Associations:
Related Sailboats:
Download Boat Record:
Notes
Later, re-introduced as the L 17.Later still, the 517, built and seen primarily in Germany is based on this same design.(Info and images from (2) original builders brochures.)
