ALLEGRO (WESTELL)

Sailboat Specifications

both US imperial metric

Hull Type:

Twin Keel

Rigging Type:

Fractional Sloop

LOA:

20.75 ft / 6.32 m

LWL:

18.42 ft / 5.61 m

Beam:

7.00 ft / 2.13 m

S.A. (reported):

199.00 ft² / 18.49 m²

Draft (max):

3.75 ft / 1.14 m

Draft (min):

1.08 ft / 0.33 m

Displacement:

1,750 lb / 794 kg

Ballast:

500 lb / 227 kg

S.A./Disp.:

21.97

Bal./Disp.:

28.57

Disp./Len.:

125.00

Construction:

Cold Molded Mahogany

Ballast Type:

Iron

First Built:

1956

Builder:

Honnor Marine Ltd. (GBR)

Designer:

John Westell

Sailboat Calculations

Definitions

S.A./Disp.:

21.97

Bal./Disp.:

28.57

Disp./Len.:

125.00

Comfort Ratio:

10.58

Capsize Screening Formula:

2.33

Sailboat Links

Designers:

John Westell

Builders:

Honnor Marine Ltd.

Download Boat Record:

PDF

Notes

The standard version featured twin, side by side, retractable, ballasted fins.
A fixed keel version was also available. Ballast is the same for both versions.
