AMIGO 40

Sailboat Specifications

both US imperial metric

Hull Type:

Long keel w/trans. hung rudder

Rigging Type:

Masthead Sloop

LOA:

30.71 ft / 9.36 m

LWL:

26.25 ft / 8.00 m

Beam:

10.01 ft / 3.05 m

S.A. (reported):

425.00 ft² / 39.48 m²

Draft (max):

4.92 ft / 1.50 m

Displacement:

12,125 lb / 5,500 kg

Ballast:

5,732 lb / 2,600 kg

S.A./Disp.:

12.93

Bal./Disp.:

47.27

Disp./Len.:

299.26

Construction:

FG

Ballast Type:

Cast iron

First Built:

1961

# Built:

48

Builder:

Arne Arksunds (SWE)

Designer:

Carl Andersson

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo Penta

Model:

2003

Type:

Diesel

Fuel:

21 gals / 79 L

Sailboat Calculations

Definitions

S.A./Disp.:

12.93

Bal./Disp.:

47.27

Disp./Len.:

299.26

Comfort Ratio:

31.58

Capsize Screening Formula:

1.75

Accommodations

Water:

53 gals / 201 L

Sailboat Links

Designers:

Olle Enderlein

Carl Andersson

Builders:

Amigo Yachts (SWE)

Download Boat Record:

PDF

Notes

The original wooden Amigo 40 was built in 1961. It is thought production of fiberglass hulls began in the 1970's. We have been told hull #19 was built in 1979.
