ANTIGUA 53

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Ketch

LOA:

51.60 ft / 15.73 m

LWL:

43.00 ft / 13.11 m

Beam:

15.00 ft / 4.57 m

S.A. (reported):

1,320.00 ft² / 122.63 m²

Draft (max):

5.16 ft / 1.57 m

Displacement:

48,000 lb / 21,772 kg

Ballast:

15,500 lb / 7,031 kg

S.A./Disp.:

16.06

Bal./Disp.:

32.29

Disp./Len.:

269.52

Construction:

FG

First Built:

1976

Builder:

Antigua Yachts (USA)

Designer:

Charles Morgan

Auxiliary Power/Tanks (orig. equip.)

Type:

Diesel

Sailboat Calculations

Definitions

S.A./Disp.:

16.06

Bal./Disp.:

32.29

Disp./Len.:

269.52

Comfort Ratio:

44.19

Capsize Screening Formula:

1.65

S#:

1.34

Rig and Sail Particulars

help

I:

58.00 ft / 17.68 m

J:

17.30 ft / 5.27 m

P:

50.00 ft / 15.24 m

E:

15.00 ft / 4.57 m

PY:

38.00 ft / 11.58 m

EY:

11.00 ft / 3.35 m

S.A. Fore:

501.70 ft² / 46.61 m²

S.A. Main:

375.00 ft² / 34.84 m²

S.A. Total (100% Fore + Main Triangles)

876.70 ft² / 81.45 m²

S.A./Disp. (calc.):

10.67

Est. Forestay Len.:

60.53 ft / 18.45 m

Sailboat Links

Designers:

Charles Morgan

Builders:

Antigua Yachts (USA)

Related Sailboats:

MORGAN OUT ISLAND 51

Download Boat Record:

PDF

Notes

Same hull as MORGAN OUT ISLAND 51 with new deck. A number of different layouts. Available in varying states of completion.
