Sailboat Specifications
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
LOA:
37.01 ft / 11.28 m
LWL:
34.78 ft / 10.60 m
Beam:
12.47 ft / 3.80 m
S.A. (reported):
831.00 ft2 / 77.20 m2
Draft (max):
6.89 ft / 2.10 m
Displacement:
15,102 lb / 6,850 kg
Ballast:
5,291 lb / 2,400 kg
S.A./Disp.:
21.84
Bal./Disp.:
35.04
Disp./Len.:
160.25
Construction:
FG
Ballast Type:
Cast iron fin with lead bulb
First Built:
2014
Builder:
Arcona Yachts (SWE)
Designer:
Stefan Qviberg
Auxiliary Power/Tanks (orig. equip.)
Make:
Yanmar
Model:
3YM30AE saildrive
Type:
Diesel
HP:
29
Fuel:
36 gals / 136 L
Sailboat Calculations
S.A./Disp.:
21.84
Bal./Disp.:
35.04
Disp./Len.:
160.25
Comfort Ratio:
22.86
Capsize Screening Formula:
2.02
S#:
3.85
Rig and Sail Particulars
I:
53.15 ft / 16.20 m
J:
13.78 ft / 4.20 m
P:
52.49 ft / 16.00 m
E:
17.72 ft / 5.40 m
S.A. Fore:
366.20 ft2 / 34.02 m2
S.A. Main:
465.06 ft2 / 43.21 m2
S.A. Total (100% Fore + Main Triangles)
831.26 ft2 / 77.23 m2
S.A./Disp. (calc.):
21.85
Est. Forestay Len.:
54.91 ft / 16.74 m
Mast Height from DWL:
64.00 ft / 19.51 m
Accommodations
Water:
53 gals / 201 L
Sailboat Links
Designers:
Builders:
Download Boat Record:
Notes
Became the 385 in 2020. Same hull and rig as the 380.Draft Shallow:1.9m/6.23' Std.:2.10m/6.89'Deep: 2.40m/7.87Hot water 25l/6.6 gal.Holding 80l/21 gal.SA (Reported):380 -Main 47.50m2/511 sq.ft. -Furling genoa (107%): 38.9m2/418.7 sq.ft. -Self tacking 29m2/312 sq.ft. -Spinnaker 138m2/1845 sq.ft. -Gennaker 146m2/1571 sq.ft.385 -Main 52 m2 / 559.7 sq.ft -107% Jib 36m2 / 387.5 sq.ft -Spinnaker 139 m2 / 1496.2 sq.ft
