ARLECCHINO 1/4 TON

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/spade rudder

Rigging Type:

Masthead Sloop

LOA:

24.54 ft / 7.48 m

LWL:

19.68 ft / 6.00 m

Beam:

8.20 ft / 2.50 m

S.A. (reported):

307.00 ft² / 28.52 m²

Draft (max):

4.59 ft / 1.40 m

Displacement:

2,646 lb / 1,200 kg

Ballast:

1,213 lb / 550 kg

S.A./Disp.:

25.74

Bal./Disp.:

45.84

Disp./Len.:

154.98

Construction:

FG

First Built:

1972

Builder:

Cantiere Sartini (ITA)

Designer:

Sciomachen

Sailboat Calculations

Definitions

S.A./Disp.:

25.74

Bal./Disp.:

45.84

Disp./Len.:

154.98

Comfort Ratio:

11.73

Capsize Screening Formula:

2.37

Sailboat Links

Designers:

Sciomachen Naval Architects

Associations:

Quarter Ton Class

Download Boat Record:

PDF

Notes

Prototype was 2nd in the 1971 Quarter Ton Cup. (La Rochelle)
Production version in 1972 by Cantiere Sartini.
