ATHENA 34

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/spade rudder

Rigging Type:

Fractional Sloop

LOA:

34.61 ft / 10.55 m

LWL:

27.56 ft / 8.40 m

Beam:

9.45 ft / 2.88 m

S.A. (reported):

539.00 ft² / 50.07 m²

Draft (max):

5.91 ft / 1.80 m

Displacement:

10,450 lb / 4,740 kg

Ballast:

4,564 lb / 2,070 kg

S.A./Disp.:

18.10

Bal./Disp.:

43.67

Disp./Len.:

222.86

Construction:

FG

Ballast Type:

Lead

First Built:

1980

Last Built:

1985

# Built:

70

Builder:

Helmsman Yachts, Saxarplast (SWE)

Designer:

Håkan Södergren

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo Penta

Type:

Diesel

Sailboat Calculations

Definitions

S.A./Disp.:

18.10

Bal./Disp.:

43.67

Disp./Len.:

222.86

Comfort Ratio:

27.32

Capsize Screening Formula:

1.73

S#:

2.56

Rig and Sail Particulars

help

I:

38.55 ft / 11.75 m

J:

12.72 ft / 3.88 m

P:

42.65 ft / 13.00 m

E:

13.78 ft / 4.20 m

S.A. Fore:

245.18 ft² / 22.78 m²

S.A. Main:

293.86 ft² / 27.30 m²

S.A. Total (100% Fore + Main Triangles)

539.04 ft² / 50.08 m²

S.A./Disp. (calc.):

18.11

Est. Forestay Len.:

40.59 ft / 12.37 m

Sailboat Links

Designers:

Håkan Södergren

Builders:

Helmsman Yachts

Finngulf Yachts

Associations:

IOR 3/4 ton

Download Boat Record:

PDF

Notes

First sold by Posiedon Yachts and built in Sweden (boats with the hull number 1-62). Some time later the molds were aquired by Finngulf Marine(FIN) where at least 10 more were built with some modifications to the deck and interior.(FINNGULF 34)
