AVANCE 245

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/transom hung rudder

Rigging Type:

Fractional Sloop

LOA:

24.54 ft / 7.48 m

LWL:

19.68 ft / 6.00 m

Beam:

8.33 ft / 2.54 m

S.A. (reported):

233.00 ft² / 21.65 m²

Draft (max):

4.67 ft / 1.42 m

Displacement:

3,858 lb / 1,750 kg

Ballast:

1,874 lb / 850 kg

S.A./Disp.:

15.20

Bal./Disp.:

48.57

Disp./Len.:

225.96

Construction:

FG

First Built:

1972

Builder:

AB Oja Batar (FIN)

Designer:

Peter Norlin

Sailboat Calculations

Definitions

S.A./Disp.:

15.20

Bal./Disp.:

48.57

Disp./Len.:

225.96

Comfort Ratio:

16.75

Capsize Screening Formula:

2.13

S#:

2.22

Rig and Sail Particulars

help

I:

27.50 ft / 8.38 m

J:

8.69 ft / 2.65 m

P:

28.50 ft / 8.69 m

E:

8.00 ft / 2.44 m

S.A. Fore:

119.49 ft² / 11.10 m²

S.A. Main:

114.00 ft² / 10.59 m²

S.A. Total (100% Fore + Main Triangles)

233.49 ft² / 21.69 m²

S.A./Disp. (calc.):

15.23

Est. Forestay Len.:

28.84 ft / 8.79 m
