AVANCE 33

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/spade rudder

Rigging Type:

Fractional Sloop

LOA:

33.79 ft / 10.30 m

LWL:

27.23 ft / 8.30 m

Beam:

8.75 ft / 2.67 m

S.A. (reported):

469.00 ft² / 43.57 m²

Draft (max):

5.48 ft / 1.67 m

Displacement:

8,818 lb / 4,000 kg

Ballast:

4,630 lb / 2,100 kg

S.A./Disp.:

17.64

Bal./Disp.:

52.51

Disp./Len.:

194.98

Construction:

FG

First Built:

1980

Last Built:

1988

Builder:

AB Oja Batar (FIN)

Designer:

Peter Norlin

Auxiliary Power/Tanks (orig. equip.)

Make:

Yanmar

Model:

2GMC

Type:

Diesel

HP:

15

Sailboat Calculations

Definitions

S.A./Disp.:

17.64

Bal./Disp.:

52.51

Disp./Len.:

194.98

Comfort Ratio:

25.96

Capsize Screening Formula:

1.70

S#:

2.84

Rig and Sail Particulars

help

I:

35.75 ft / 10.90 m

J:

11.81 ft / 3.60 m

P:

40.29 ft / 12.28 m

E:

12.79 ft / 3.90 m

S.A. Fore:

211.10 ft² / 19.61 m²

S.A. Main:

257.65 ft² / 23.94 m²

S.A. Total (100% Fore + Main Triangles)

468.76 ft² / 43.55 m²

S.A./Disp. (calc.):

17.63

Est. Forestay Len.:

37.65 ft / 11.48 m

Mast Height from DWL:

48.40 ft / 14.75 m

Sailboat Links

Designers:

Peter Norlin

Builders:

Avance Yachts

Download Boat Record:

PDF

Notes

From sales brochure.
Tall (masthead) rig:
I:38.00'
J:11.81'
P:40.25'
E:12.79'
