BAVARIA 40 (J&J)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin Keel w/bulb

Rigging Type:

Fractional Sloop

LOA:

40.90 ft / 12.47 m

LWL:

35.83 ft / 10.92 m

Beam:

13.00 ft / 3.96 m

S.A. (reported):

790.00 ft² / 73.39 m²

Draft (max):

6.40 ft / 1.95 m

Displacement:

17,420 lb / 7,902 kg

Ballast:

6,265 lb / 2,842 kg

S.A./Disp.:

18.88

Bal./Disp.:

35.96

Disp./Len.:

169.07

Construction:

FG w/Divinicell above waterline

First Built:

2000

Builder:

Bavaria Yachts (GER)

Designer:

J&J Design

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo Penta

Model:

MD2030

Type:

Diesel

HP:

50

Fuel:

40 gals / 151 L

Sailboat Calculations

Definitions

S.A./Disp.:

18.88

Bal./Disp.:

35.96

Disp./Len.:

169.07

Comfort Ratio:

23.67

Capsize Screening Formula:

2.01

Accommodations

Water:

80 gals / 303 L

Sailboat Links

Designers:

J&J Design

Builders:

Bavaria Yachts (GER)

Download Boat Record:

PDF

Notes

Popular in the charter trade.
