SailboatData.com - CAL 22 Sailboat

CAL 22

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/transom hung rudder

Rigging Type:

Fractional Sloop

LOA:

22.00 ft / 6.71 m

LWL:

19.50 ft / 5.94 m

Beam:

7.75 ft / 2.36 m

S.A. (reported):

223.00 ft² / 20.72 m²

Draft (max):

3.50 ft / 1.07 m

Displacement:

2,100 lb / 953 kg

Ballast:

775 lb / 352 kg

S.A./Disp.:

21.81

Bal./Disp.:

36.90

Disp./Len.:

126.44

Construction:

First Built:

1984

Last Built:

1997

Builder:

Bangor Punta Marine (USA)

Designer:

C. R. Hunt Assoc.

Sailboat Calculations

Definitions

S.A./Disp.:

21.81

Bal./Disp.:

36.90

Disp./Len.:

126.44

Comfort Ratio:

10.47

Capsize Screening Formula:

2.42

S#:

4.46

Rig and Sail Particulars

help

24.60 ft / 7.50 m

8.40 ft / 2.56 m

25.80 ft / 7.86 m

9.30 ft / 2.83 m

S.A. Fore:

103.32 ft² / 9.60 m²

S.A. Main:

119.97 ft² / 11.15 m²

S.A. Total (100% Fore + Main Triangles)

223.29 ft² / 20.74 m²

S.A./Disp. (calc.):

21.84

Est. Forestay Len.:

25.99 ft / 7.92 m

Sailboat Links

Designers:

Raymond Hunt (C.R. Hunt & Assoc.)

Builders:

Jensen Marine/Cal Boats

Bangor Punta Corp.

Lear Siegler Inc.

Download Boat Record:

PDF

Notes

Shoal Draft version.
draft - 2.83
disp. - 2275
ballast. - 925
Some boats were sold with a masthead rig.
I: 29.3'
J: 8.4'
P: 25.8'
E: 9.2'
