CIRRUS 22 (WESTERLY)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/spade rudder

Rigging Type:

Fractional Sloop

LOA:

22.00 ft / 6.71 m

LWL:

19.00 ft / 5.79 m

Beam:

8.00 ft / 2.44 m

S.A. (reported):

233.00 ft² / 21.65 m²

Draft (max):

3.50 ft / 1.07 m

Displacement:

3,240 lb / 1,470 kg

Ballast:

1,455 lb / 660 kg

S.A./Disp.:

17.07

Bal./Disp.:

44.91

Disp./Len.:

210.88

Construction:

FG

First Built:

1968

Last Built:

1972

# Built:

398

Builder:

Westerly Marine Ltd. (UK)

Designer:

John Butler

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo

Model:

MD1

Type:

Diesel

Fuel:

7 gals / 26 L

Sailboat Calculations

Definitions

S.A./Disp.:

17.07

Bal./Disp.:

44.91

Disp./Len.:

210.88

Comfort Ratio:

15.76

Capsize Screening Formula:

2.17

S#:

2.59

Rig and Sail Particulars

help

I:

26.00 ft / 7.92 m

J:

8.67 ft / 2.64 m

P:

26.67 ft / 8.13 m

E:

9.00 ft / 2.74 m

S.A. Fore:

112.71 ft² / 10.47 m²

S.A. Main:

120.02 ft² / 11.15 m²

S.A. Total (100% Fore + Main Triangles)

232.73 ft² / 21.62 m²

S.A./Disp. (calc.):

17.05

Est. Forestay Len.:

27.41 ft / 8.35 m

Sailboat Links

Designers:

John A. Butler

Builders:

Westerly Marine Construction Ltd.

Associations:

Westerly Owners Association

Download Boat Record:

PDF

Notes

The diesel inboard was an option.
Some have taller rig.
