CROMARTY 36

Sailboat Specifications

both US imperial metric

Hull Type:

Long Keel

Rigging Type:

Masthead Ketch

LOA:

36.09 ft / 11.00 m

LWL:

26.67 ft / 8.13 m

Beam:

12.00 ft / 3.66 m

S.A. (reported):

826.00 ft² / 76.74 m²

Draft (max):

4.63 ft / 1.41 m

Displacement:

19,039 lb / 8,636 kg

Ballast:

6,720 lb / 3,048 kg

S.A./Disp.:

18.61

Bal./Disp.:

35.30

Disp./Len.:

448.05

Construction:

FG

First Built:

1988

Builder:

Blondecell Ltd. (UK)

Designer:

Wyatt & Freeman

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo Penta

Model:

D2

Type:

Diesel

HP:

55

Fuel:

120 gals / 454 L

Sailboat Calculations

Definitions

S.A./Disp.:

18.61

Bal./Disp.:

35.30

Disp./Len.:

448.05

Comfort Ratio:

36.45

Capsize Screening Formula:

1.80

Accommodations

Water:

120 gals / 454 L

Sailboat Links

Designers:

Wyatt and Freeman

Builders:

Neil Marine (Neil Fernando & Co. Pvt. Ltd.)

Download Boat Record:

PDF

Notes

Later re-introduced by Neil Marine in Sri Lanka, and fitted out in UK.
