DAWN 39

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Sloop

LOA:

39.33 ft / 11.99 m

LWL:

30.00 ft / 9.14 m

Beam:

11.33 ft / 3.45 m

S.A. (reported):

875.00 ft² / 81.29 m²

Draft (max):

6.25 ft / 1.91 m

Displacement:

16,000 lb / 7,257 kg

Ballast:

7,716 lb / 3,500 kg

S.A./Disp.:

22.13

Bal./Disp.:

48.23

Disp./Len.:

264.55

Construction:

FG

Ballast Type:

Lead

First Built:

2001

Builder:

Pointer Yachts (UK)

Designer:

David Alan-Williams

Auxiliary Power/Tanks (orig. equip.)

Make:

Yanmar

Model:

3HM 35P

Type:

Diesel

HP:

30

Fuel:

40 gals / 151 L

Sailboat Calculations

Definitions

S.A./Disp.:

22.13

Bal./Disp.:

48.23

Disp./Len.:

264.55

Comfort Ratio:

29.73

Capsize Screening Formula:

1.80

Accommodations

Water:

75 gals / 284 L

Sailboat Links

Designers:

David Alan-Williams

Builders:

Pointer Yachts (UK)

Related Sailboats:

CONTESSA 38 (ALAN-WILLIAMS)

Download Boat Record:

PDF

Notes

Derived from the CONTESSA 38 built by Jeremy Rodgers. Thanks to Nick Voss for providing information on this yacht.
