ERICSON 34

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/spade rudder

Rigging Type:

Masthead Sloop

LOA:

34.12 ft / 10.40 m

LWL:

28.87 ft / 8.80 m

Beam:

10.75 ft / 3.28 m

S.A. (reported):

494.00 ft² / 45.89 m²

Draft (max):

5.92 ft / 1.80 m

Displacement:

10,000 lb / 4,536 kg

Ballast:

5,000 lb / 2,268 kg

S.A./Disp.:

17.09

Bal./Disp.:

50.00

Disp./Len.:

185.53

Construction:

FG

First Built:

1978

Builder:

Ericson Yachts (USA)

Designer:

Bruce King

Sailboat Calculations

Definitions

S.A./Disp.:

17.09

Bal./Disp.:

50.00

Disp./Len.:

185.53

Comfort Ratio:

21.47

Capsize Screening Formula:

2.00

S#:

2.90

Rig and Sail Particulars

help

I:

43.00 ft / 13.11 m

J:

13.83 ft / 4.22 m

P:

38.00 ft / 11.58 m

E:

10.37 ft / 3.16 m

S.A. Fore:

297.35 ft² / 27.62 m²

S.A. Main:

197.03 ft² / 18.30 m²

S.A. Total (100% Fore + Main Triangles)

494.38 ft² / 45.93 m²

S.A./Disp. (calc.):

17.10

Est. Forestay Len.:

45.17 ft / 13.77 m

Sailboat Links

Designers:

Bruce King

Builders:

Ericson Yachts (USA)

Associations:

Ericson Yachts Information

Related Sailboats:

ERICSON 34T

Download Boat Record:

PDF

Notes

Sometimes referred to as the 34X, this is the 'blister' decked version of the ERICSON 34 designed to the IOR rule. The 34T shares the same hull but with a trunk cabin. A later boat, the ERICSON 34-2, is a completely different design.
