Sailboat Specifications
Hull Type:
Long keel w/trans. hung rudder
Rigging Type:
Masthead Ketch
LOA:
34.33 ft / 10.46 m
LWL:
29.85 ft / 9.10 m
Beam:
11.22 ft / 3.42 m
S.A. (reported):
525.00 ft2 / 48.77 m2
Draft (max):
4.73 ft / 1.44 m
Displacement:
25,759 lb / 11,684 kg
Ballast:
10,640 lb / 4,826 kg
S.A./Disp.:
9.67
Bal./Disp.:
41.31
Disp./Len.:
432.36
Construction:
FG
First Built:
1978
Builder:
Fairways Marine/Northshore Yachts Ltd. (UK)
Designer:
Wyatt and Freeman
Auxiliary Power/Tanks (orig. equip.)
Type:
Diesel
HP:
60
Fuel:
96 gals / 364 L
Sailboat Calculations
S.A./Disp.:
9.67
Bal./Disp.:
41.31
Disp./Len.:
432.36
Comfort Ratio:
50.99
Capsize Screening Formula:
1.52
Accommodations
Water:
96 gals / 364 L
Sailboat Links
Designers:
Builders:
Associations:
Download Boat Record:
Notes
Sloop or ketch.Specs above are from an original Fairways Marine brochure. Later Northshore and Neil Marine docs indicate a draft of 1.49m / 4.92ft; 75 -80 hp Yanmar engines; and a sail area for the ketch rig of 58.14 m² / 626 ft²Thanks to 'olddog57' for providing corrections.
