GEMINI (CAPE COD)

GEMINI (CAPE COD)
GEMINI (CAPE COD)

Beta Marine

Beta Marine

Sailboat Specifications

Definitions
Hull Type: Twin Centerboards
Rigging Type: Fractional Sloop
LOA: 16.08 ft / 4.90 m
LWL: 14.75 ft / 4.50 m
S.A. (reported): 140.00 ft² / 13.01 m²
Beam: 5.58 ft / 1.70 m
Displacement: 440.00 lb / 200 kg
Max Draft: 3.33 ft / 1.01 m
Min Draft: 0.58 ft / 0.18 m
Construction: Wood/FG
First Built: 1955
# Built: 150
Builder: Cape Cod Shipbuilding (USA)
Designer: Sidney Herreshoff

KLSC Leaderboard

KLSC Leaderboard

Sailboat Calculations

Definitions
S.A. / Displ.: 38.77
Disp: / Len: 61.21
Comfort Ratio: 4.54
Capsize Screening Formula: 2.94
Hull Speed: 5.15 kn
Pounds/Inch Immersion: 294.08 pounds/inch

calculation mobile

2 nd ad half width

3rd ad full width

Sailboat Links

Designers: A. Sidney DeWolf Herreshoff
Builders: Cape Cod Shipbuilding
Herreshoff Mfg. Co.
Download Boat Record:

Notes

Originally built by Herreshoff Manufacturing.
Features twin, side by side, centerboards.
