GP 26 (DONOVAN)

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Fractional Sloop

LOA:

25.92 ft / 7.90 m

LWL:

25.92 ft / 7.90 m

Beam:

8.37 ft / 2.55 m

S.A. (reported):

350.00 ft² / 32.52 m²

Draft (max):

6.23 ft / 1.90 m

Displacement:

2,205 lb / 1,000 kg

Ballast:

1,102 lb / 500 kg

S.A./Disp.:

33.13

Bal./Disp.:

49.98

Disp./Len.:

56.53

Construction:

FG

Ballast Type:

Lead

First Built:

2011

Builder:

Windseeker Yachts (TURKEY)

Designer:

Donovan

Sailboat Calculations

Definitions

S.A./Disp.:

33.13

Bal./Disp.:

49.98

Disp./Len.:

56.53

Comfort Ratio:

7.76

Capsize Screening Formula:

2.58

S#:

7.96

Rig and Sail Particulars

help

I:

30.35 ft / 9.25 m

J:

9.51 ft / 2.90 m

P:

32.48 ft / 9.90 m

E:

12.63 ft / 3.85 m

SPL/TPS:

15.75 ft / 4.80 m

ISP:

36.58 ft / 11.15 m

S.A. Fore:

144.31 ft² / 13.41 m²

S.A. Main:

205.11 ft² / 19.06 m²

S.A. Total (100% Fore + Main Triangles)

349.43 ft² / 32.46 m²

S.A./Disp. (calc.):

33.08

Est. Forestay Len.:

31.81 ft / 9.69 m

Sailboat Links

Designers:

J. P. Donovan

Builders:

W Raceboats

Download Boat Record:

PDF

Notes

Designed by Donovan to GP 26 (ORC box)rule.
Carbon spars std.
Draft is 3.5' with keel up.
Lifting rudder in cassette, opt.
