GRAND SOLEIL 45 PERFORMANCE

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Fractional Sloop

LOA:

45.60 ft / 13.90 m

LWL:

39.37 ft / 12.00 m

Beam:

13.98 ft / 4.26 m

S.A. (reported):

1,130.21 ft² / 105.00 m²

Draft (max):

7.55 ft / 2.30 m

Displacement:

21,164 lb / 9,600 kg

Ballast:

6,834 lb / 3,100 kg

S.A./Disp.:

23.73

Bal./Disp.:

32.29

Disp./Len.:

154.83

Construction:

FG w/foam PVC sandwich

First Built:

2004

Last Built:

2010

Builder:

Cantiere del Pardo (ITA)

Designer:

Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo Penta

Type:

Diesel

HP:

40

Fuel:

61 gals / 230 L

Sailboat Calculations

Definitions

S.A./Disp.:

23.73

Bal./Disp.:

32.29

Disp./Len.:

154.83

Comfort Ratio:

23.65

Capsize Screening Formula:

2.03

Accommodations

Water:

106 gals / 400 L

Sailboat Links

Designers:

Judel/Vrolijk & Co.

Builders:

Grand Soleil (Cantiere del Pardo)

Download Boat Record:

PDF

Notes

Hull length: 13.55m / 44.45ft
Deep keel draft: 2.7m / 8.86ft
Shallow keel draft: 1.95m / 6.4ft
