Sailboat Specifications
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
LOA:
31.56 ft / 9.62 m
LWL:
27.10 ft / 8.26 m
Beam:
10.83 ft / 3.30 m
S.A. (reported):
606.01 ft2 / 56.30 m2
Draft (max):
5.61 ft / 1.71 m
Displacement:
9,921 lb / 4,500 kg
Ballast:
4,409 lb / 2,000 kg
S.A./Disp.:
21.07
Bal./Disp.:
44.44
Disp./Len.:
222.54
Construction:
FG
Ballast Type:
Lead
First Built:
1992
Last Built:
2009
# Built:
356
Builder:
Hallberg-Rassy
Designer:
German Frers
Auxiliary Power/Tanks (orig. equip.)
Make:
Volvo Penta
Model:
2002
Type:
Diesel
Fuel:
16 gals / 60 L
Sailboat Calculations
S.A./Disp.:
21.07
Bal./Disp.:
44.44
Disp./Len.:
222.54
Comfort Ratio:
22.58
Capsize Screening Formula:
2.02
Rig and Sail Particulars
Mast Height from DWL:
48.56 ft / 14.80 m
Accommodations
Headroom:
6.10 ft / 1.86 m
Water:
50 gals / 190 L
Notes
Shallow draft keel: 1.41 m / 4.62 ft.Later models had a Volvo Penta 2020 engine.S.A.(reported) above is Main + Genoa. S.A with Main + Jib is 46 m² / 495 ft²The early ‘92's were delivered without a fixed windshield.Thanks to Luuk Jansen for information and corrections.
