HALLBERG-RASSY 40 MKII

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/rudder on partial skeg

Rigging Type:

Masthead Sloop

LOA:

40.68 ft / 12.40 m

LWL:

36.35 ft / 11.08 m

Beam:

12.53 ft / 3.82 m

S.A. (reported):

877.00 ft² / 81.48 m²

Draft (max):

6.53 ft / 1.99 m

Displacement:

24,250 lb / 11,000 kg

Ballast:

9,039 lb / 4,100 kg

S.A./Disp.:

16.82

Bal./Disp.:

37.27

Disp./Len.:

225.40

Construction:

GRP

Ballast Type:

Lead

First Built:

2015

Last Built:

2018

# Built:

6

Builder:

Hallberg-Rassy

Designer:

Germán Frers

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo Penta

Model:

D2-60

Type:

Diesel

HP:

60

Fuel:

118 gals / 445 L

Sailboat Calculations

Definitions

S.A./Disp.:

16.82

Bal./Disp.:

37.27

Disp./Len.:

225.40

Comfort Ratio:

34.34

Capsize Screening Formula:

1.74

Rig and Sail Particulars

help

Mast Height from DWL:

60.86 ft / 18.55 m

Accommodations

Headroom:

6.29 ft / 1.92 m

Water:

122 gals / 460 L

Sailboat Links

Designers:

German Frers

Builders:

Hallberg-Rassy

Associations:

Hallberg-Rassy

Hallberg-Rassy Owners Association (UK)

Related Sailboats:

HALLBERG-RASSY 40

Download Boat Record:

PDF

Notes

Updated version of the HR 40. Slightly more SA and taller rig (+25cm).
Available with s shallow draft keel: 1.69m / 5.54 ft
