Sailboat Specifications
Hull Type:
Fin w/rudder on partial skeg
Rigging Type:
Masthead Sloop
LOA:
46.33 ft / 14.12 m
LWL:
38.06 ft / 11.60 m
Beam:
14.17 ft / 4.32 m
S.A. (reported):
1,017.94 ft2 / 94.57 m2
Draft (max):
6.17 ft / 1.88 m
Displacement:
35,274 lb / 16,000 kg
Ballast:
14,110 lb / 6,400 kg
S.A./Disp.:
15.21
Bal./Disp.:
40.00
Disp./Len.:
285.63
Construction:
GRP
Ballast Type:
Lead
First Built:
1988
Last Built:
1996
# Built:
71
Builder:
Hallberg-Rassy
Designer:
Germán Frers
Auxiliary Power/Tanks (orig. equip.)
Make:
Volvo Penta
Model:
TMD 31A
Type:
Diesel
HP:
94
Fuel:
156 gals / 590 L
Sailboat Calculations
S.A./Disp.:
15.21
Bal./Disp.:
40.00
Disp./Len.:
285.63
Comfort Ratio:
39.38
Capsize Screening Formula:
1.73
S#:
1.71
Rig and Sail Particulars
I:
59.06 ft / 18.00 m
J:
18.54 ft / 5.65 m
P:
52.17 ft / 15.90 m
E:
18.04 ft / 5.50 m
S.A. Fore:
547.49 ft2 / 50.86 m2
S.A. Main:
470.57 ft2 / 43.72 m2
S.A. Total (100% Fore + Main Triangles)
1,018.06 ft2 / 94.58 m2
S.A./Disp. (calc.):
15.21
Est. Forestay Len.:
61.90 ft / 18.87 m
Mast Height from DWL:
63.65 ft / 19.40 m
Accommodations
Water:
264 gals / 1,000 L
