HALLBERG-RASSY 48

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/rudder on partial skeg

Rigging Type:

Masthead Sloop

LOA:

49.18 ft / 14.99 m

LWL:

43.47 ft / 13.25 m

Beam:

14.76 ft / 4.50 m

S.A. (reported):

1,328.27 ft² / 123.40 m²

Draft (max):

7.71 ft / 2.35 m

Displacement:

40,786 lb / 18,500 kg

Ballast:

17,086 lb / 7,750 kg

S.A./Disp.:

18.01

Bal./Disp.:

41.89

Disp./Len.:

221.66

Construction:

GRP

Ballast Type:

Lead

First Built:

2004

Last Built:

2013

# Built:

69

Builder:

Hallberg-Rassy

Designer:

Germán Frers

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo Penta

Model:

D3-110

Type:

Diesel

HP:

110

Fuel:

211 gals / 800 L

Sailboat Calculations

Definitions

S.A./Disp.:

18.01

Bal./Disp.:

41.89

Disp./Len.:

221.66

Comfort Ratio:

38.70

Capsize Screening Formula:

1.72

Rig and Sail Particulars

help

Mast Height from DWL:

71.36 ft / 21.75 m

Accommodations

Headroom:

6.53 ft / 1.99 m

Water:

240 gals / 910 L

Sailboat Links

Designers:

German Frers

Builders:

Hallberg-Rassy

Associations:

Hallberg-Rassy

Hallberg-Rassy Owners Association (UK)

Download Boat Record:

PDF

Notes

Shallow draft option available. Draft: 2m / 6.56ft.
