HANSA-JOLLE

Sailboat Specifications

both US imperial metric

Hull Type:

Keel/Cbrd.

Rigging Type:

Fractional Sloop

LOA:

19.19 ft / 5.85 m

LWL:

15.91 ft / 4.85 m

Beam:

5.41 ft / 1.65 m

S.A. (reported):

151.00 ft² / 14.03 m²

Draft (max):

3.28 ft / 1.00 m

Draft (min):

1.64 ft / 0.50 m

Displacement:

1,212 lb / 550 kg

Ballast:

331 lb / 150 kg

S.A./Disp.:

21.30

Bal./Disp.:

27.31

Disp./Len.:

134.35

Construction:

Wood/FG

First Built:

1947

Builder:

Abeking & Rasmussen

Designer:

Henry Rasmussen

Sailboat Calculations

Definitions

S.A./Disp.:

21.30

Bal./Disp.:

27.31

Disp./Len.:

134.35

Comfort Ratio:

11.69

Capsize Screening Formula:

2.03

Sailboat Links

Builders:

Mader Bootswerft

Abeking & Rasmussen

Associations:

Hansa Jolle class (Germany)

Download Boat Record:

PDF

Notes

Fiberglass version introduced in 1977. (built by L. Mader 1977-1981) A number of other builders later.
Mostly seen on the Bavarian lakes, Lake Constance, _Dümmer Lake Steinhude and the reservoirs in North Rhine-Westphalia.
