Sailboat Specifications
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
LOA:
31.56 ft / 9.62 m
LWL:
28.54 ft / 8.70 m
Beam:
10.99 ft / 3.35 m
S.A. (reported):
505.00 ft2 / 46.92 m2
Draft (max):
6.07 ft / 1.85 m
Displacement:
10,362 lb / 4,700 kg
Ballast:
3,307 lb / 1,500 kg
S.A./Disp.:
17.06
Bal./Disp.:
31.91
Disp./Len.:
198.99
Construction:
FG
First Built:
2016
Builder:
Hanse Yachts
Designer:
Judel/Vrolijk
Auxiliary Power/Tanks (orig. equip.)
Type:
Diesel
HP:
12
Fuel:
26 gals / 98 L
Sailboat Calculations
S.A./Disp.:
17.06
Bal./Disp.:
31.91
Disp./Len.:
198.99
Comfort Ratio:
22.33
Capsize Screening Formula:
2.02
S#:
2.64
Rig and Sail Particulars
I:
38.71 ft / 11.80 m
J:
11.38 ft / 3.47 m
P:
37.73 ft / 11.50 m
E:
13.94 ft / 4.25 m
S.A. Fore:
220.26 ft2 / 20.46 m2
S.A. Main:
262.98 ft2 / 24.43 m2
S.A. Total (100% Fore + Main Triangles)
483.24 ft2 / 44.89 m2
S.A./Disp. (calc.):
16.32
Est. Forestay Len.:
40.35 ft / 12.30 m
Mast Height from DWL:
47.10 ft / 14.36 m
Accommodations
Water:
61 gals / 231 L
Notes
Shallow Draft (opt): 1.35 m | 4.16´Ballast for shallow draft: 1.500 kg | 3307 lbsTotal (upwind) sail area 47.00 m² | 506 sq ftMain sail approx. 29.50 m² | approx. 318 sq ftSelf-tacking jib approx. 17.50 m² | approx. 188 sq ft.Interior HanseYachts Design
