Sailboat Specifications
Hull Type:
Fin w/bulb & spade rudder
Rigging Type:
Fractional Sloop
LOA:
36.91 ft / 11.25 m
LWL:
32.32 ft / 9.85 m
Beam:
11.78 ft / 3.59 m
S.A. (reported):
710.00 ft2 / 65.96 m2
Draft (max):
6.50 ft / 1.98 m
Displacement:
14,550 lb / 6,600 kg
Ballast:
5,291 lb / 2,400 kg
S.A./Disp.:
19.13
Bal./Disp.:
36.36
Disp./Len.:
192.40
Construction:
FG
Ballast Type:
Lead
First Built:
1999
Last Built:
2005
Builder:
Hanse
Designer:
Judel/Vrolijk
Auxiliary Power/Tanks (orig. equip.)
Make:
Volvo
Model:
MD 2030
Type:
Diesel
Fuel:
21 gals / 79 L
Sailboat Calculations
S.A./Disp.:
19.13
Bal./Disp.:
36.36
Disp./Len.:
192.40
Comfort Ratio:
24.99
Capsize Screening Formula:
1.93
Accommodations
Water:
58 gals / 220 L
Notes
Draft: 1,98 m (1,69 m/1,08 m Option)Mainsail: 38 m²Self tacking jib: 28.5 m²Storm jib: 10 m² (Option)Genoa: ca. 40 m² (Option)Spinnaker: ca. 100 m² (Option)
