HANSE 461

Sailboat Specifications

both US imperial metric

Hull Type:

Fin Keel w/bulb

Rigging Type:

Fractional Sloop

LOA:

45.93 ft / 14.00 m

LWL:

41.34 ft / 12.60 m

Beam:

14.67 ft / 4.47 m

S.A. (reported):

1,160.00 ft² / 107.77 m²

Draft (max):

7.55 ft / 2.30 m

Displacement:

26,235 lb / 11,900 kg

Ballast:

7,584 lb / 3,440 kg

S.A./Disp.:

21.11

Bal./Disp.:

28.91

Disp./Len.:

165.78

Construction:

FG

First Built:

2005

Builder:

Hanse Yachts

Designer:

Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Make:

Yanmar

Model:

4JH4

Type:

Diesel

HP:

75

Fuel:

66 gals / 250 L

Sailboat Calculations

Definitions

S.A./Disp.:

21.11

Bal./Disp.:

28.91

Disp./Len.:

165.78

Comfort Ratio:

26.55

Capsize Screening Formula:

1.98

S#:

3.67

Rig and Sail Particulars

help

I:

62.62 ft / 19.09 m

J:

17.45 ft / 5.32 m

P:

65.62 ft / 20.00 m

E:

18.70 ft / 5.70 m

S.A. Fore:

546.36 ft² / 50.76 m²

S.A. Main:

613.55 ft² / 57.00 m²

S.A. Total (100% Fore + Main Triangles)

1,159.91 ft² / 107.76 m²

S.A./Disp. (calc.):

21.10

Est. Forestay Len.:

65.01 ft / 19.81 m

Mast Height from DWL:

80.15 ft / 24.43 m

Accommodations

Water:

106 gals / 401 L

Sailboat Links

Designers:

Judel/Vrolijk & Co.

Builders:

Hanse Yachts

Download Boat Record:

PDF

Notes

Deep draft:2.60 m / 8.42´
