HANSE 540E

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Fractional Sloop

LOA:

52.76 ft / 16.08 m

LWL:

47.90 ft / 14.60 m

Beam:

16.11 ft / 4.91 m

S.A. (reported):

1,435.00 ft² / 133.32 m²

Draft (max):

9.19 ft / 2.80 m

Displacement:

41,226 lb / 18,700 kg

Ballast:

12,787 lb / 5,800 kg

S.A./Disp.:

19.32

Bal./Disp.:

31.02

Disp./Len.:

167.46

Construction:

FG

Ballast Type:

Lead

First Built:

2006

Builder:

Hanse Yachts

Designer:

Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo

Type:

Diesel

HP:

110

Fuel:

99 gals / 375 L

Sailboat Calculations

Definitions

S.A./Disp.:

19.32

Bal./Disp.:

31.02

Disp./Len.:

167.46

Comfort Ratio:

31.88

Capsize Screening Formula:

1.87

S#:

3.42

Rig and Sail Particulars

help

I:

69.72 ft / 21.25 m

J:

19.65 ft / 5.99 m

P:

70.37 ft / 21.45 m

E:

21.33 ft / 6.50 m

S.A. Fore:

685.00 ft² / 63.64 m²

S.A. Main:

750.50 ft² / 69.72 m²

S.A. Total (100% Fore + Main Triangles)

1,435.50 ft² / 133.36 m²

S.A./Disp. (calc.):

19.33

Est. Forestay Len.:

72.44 ft / 22.08 m

Accommodations

Water:

182 gals / 689 L
