HANSE 545

Sailboat Specifications

both US imperial metric

Hull Type:

Fin w/bulb & spade rudder

Rigging Type:

Fractional Sloop

LOA:

53.15 ft / 16.20 m

LWL:

47.90 ft / 14.60 m

Beam:

16.11 ft / 4.91 m

S.A. (reported):

1,447.00 ft² / 134.43 m²

Draft (max):

9.19 ft / 2.80 m

Displacement:

41,226 lb / 18,700 kg

Ballast:

12,787 lb / 5,800 kg

S.A./Disp.:

19.48

Bal./Disp.:

31.02

Disp./Len.:

167.46

Construction:

FG

Ballast Type:

Lead

First Built:

2008

Builder:

Hanse Yachts

Designer:

Judel/Vrolijk

Auxiliary Power/Tanks (orig. equip.)

Make:

Yanmar

Type:

Diesel

HP:

110

Fuel:

106 gals / 401 L

Sailboat Calculations

Definitions

S.A./Disp.:

19.48

Bal./Disp.:

31.02

Disp./Len.:

167.46

Comfort Ratio:

31.80

Capsize Screening Formula:

1.87

S#:

3.44

Rig and Sail Particulars

help

I:

69.72 ft / 21.25 m

J:

19.98 ft / 6.09 m

P:

70.37 ft / 21.45 m

E:

21.33 ft / 6.50 m

S.A. Fore:

696.50 ft² / 64.71 m²

S.A. Main:

750.50 ft² / 69.72 m²

S.A. Total (100% Fore + Main Triangles)

1,447.00 ft² / 134.43 m²

S.A./Disp. (calc.):

19.48

Est. Forestay Len.:

72.53 ft / 22.11 m

Mast Height from DWL:

86.20 ft / 26.27 m

Accommodations

Water:

185 gals / 700 L

Sailboat Links

Designers:

Judel/Vrolijk & Co.

Builders:

Hanse Yachts

Download Boat Record:

PDF

Notes

Shallow draft: 2.43m 7.97'
Shallower draft: 1.95m 6.4'
