HYLAS 45.5

Sailboat Specifications

both US imperial metric

Hull Type:

Fin with rudder on skeg

Rigging Type:

Masthead Sloop

LOA:

46.00 ft / 14.02 m

LWL:

38.00 ft / 11.58 m

Beam:

13.50 ft / 4.11 m

S.A. (reported):

866.00 ft² / 80.45 m²

Draft (max):

6.67 ft / 2.03 m

Displacement:

22,320 lb / 10,124 kg

Ballast:

11,020 lb / 4,999 kg

S.A./Disp.:

17.55

Bal./Disp.:

49.37

Disp./Len.:

181.59

Construction:

FG

First Built:

1993

Builder:

Queen Long Marine Co, Ltd. (TAIWAN)

Designer:

German Frers

Auxiliary Power/Tanks (orig. equip.)

Make:

Yanmar

Type:

Diesel

Fuel:

80 gals / 303 L

Sailboat Calculations

Definitions

S.A./Disp.:

17.55

Bal./Disp.:

49.37

Disp./Len.:

181.59

Comfort Ratio:

26.67

Capsize Screening Formula:

1.92

S#:

3.00

Rig and Sail Particulars

help

I:

55.00 ft / 16.76 m

J:

17.80 ft / 5.43 m

P:

47.00 ft / 14.33 m

E:

16.00 ft / 4.88 m

S.A. Fore:

489.50 ft² / 45.48 m²

S.A. Main:

376.00 ft² / 34.93 m²

S.A. Total (100% Fore + Main Triangles)

865.50 ft² / 80.41 m²

S.A./Disp. (calc.):

17.54

Est. Forestay Len.:

57.81 ft / 17.62 m

Accommodations

Water:

180 gals / 681 L

Sailboat Links

Designers:

German Frers

Builders:

Queen Long Marine

Hylas Yachts USA

Associations:

Hylas Yachts Owners Association

Hylas Yacht Club

Download Boat Record:

PDF

Notes

Same as HYLAS 44 but with extended transom w/swim ladder.
