LAVEZZI 40

Sailboat Specifications

both imperial metric

Hull Type:

Catamaran Twin Keel

Rigging Type:

Frac. Sloop (Rotating Spar)

LOA:

39.10 ft / 11.92 m

LWL:

39.10 ft / 11.92 m

Beam:

21.40 ft / 6.52 m

S.A. (reported):

969.00 ft² / 90.02 m²

Draft (max):

3.60 ft / 1.10 m

Draft (min):

Displacement:

13,228 lb / 6,000 kg

Ballast:

S.A./Disp.:

27.82

Bal./Disp.:

Disp./Len.:

98.79

Construction:

FG

Ballast Type:

First Built:

2002

Last Built:

2009

# Built:

227

Builder:

Fountaine Pajot Catamarans (FRA)

Designer:

O. Flahault Design /Joubert - Nivelt

Website:

Auxiliary Power/Tanks (orig. equip.)

Make:

Volvo

Model:

2030

Type:

Diesel X 2

HP:

36

Water:

145 gals / 549 L

Fuel:

66 gals / 250 L

Sailboat Calculations

help

S.A./Disp.:

27.82

Bal./Disp.:

Disp./Len.:

98.79

Capsize Screening Formula:

3.63

Rig and Sail Particulars

help

Mast Height from DWL:

57.58 ft / 17.55 m

Sailboat Links

Designers:

Joubert-Nivelt

Flahault Design & Associates

Builders:

Fountaine Pajot

Notes

Charter version has four double cabins.
Owner's version with owner's cabin occupying one hull.
