Sailboat Specifications
Hull Type:
Fin w/spade rudder
Rigging Type:
Fractional Sloop
LOA:
44.50 ft / 13.56 m
LWL:
38.58 ft / 11.76 m
Beam:
12.50 ft / 3.81 m
S.A. (reported):
1,383.00 ft2 / 128.48 m2
Draft (max):
7.25 ft / 2.21 m
Displacement:
26,000 lb / 11,793 kg
Ballast:
10,000 lb / 4,536 kg
S.A./Disp.:
25.31
Bal./Disp.:
38.46
Disp./Len.:
202.13
Construction:
FG
Ballast Type:
Lead
First Built:
2005
# Built:
8
Builder:
Morris Yachts
Designer:
David Pedrick
Auxiliary Power/Tanks (orig. equip.)
Make:
Yanmar
Model:
4JH
Type:
Diesel
HP:
54
Fuel:
50 gals / 189 L
Sailboat Calculations
S.A./Disp.:
25.31
Bal./Disp.:
38.46
Disp./Len.:
202.13
Comfort Ratio:
34.46
Capsize Screening Formula:
1.69
Rig and Sail Particulars
Mast Height from DWL:
68.00 ft / 20.73 m
Accommodations
Water:
130 gals / 492 L
Notes
Built primarily for use at the U.S. Coast Guard Academy and replacements for the Luders 44 yawls, originally built for the U.S .Naval Academy in the 1960's. It is thought that this is an updated version of the NA 44 of the 1980's. (McCurdy & Rhodes) Also referred to as DEFIANCE class.
